Project Description
Description
BM350 automatic high-speed chocolate pillow packing machine is suitable for packing regular objects such as biscuit, egg pie, bread, chocolate, candy, instant noodle, moon cakes, hardware, daily consuming ware, industrial parts, paper box or trays.
Feature
- The machine uses servomotor, flexible bag length cutting, the operator needn’t adjust the unloading working, saving time and films.
- High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.
- Simple driving system, reliable working, convenient maintenance.
Packaging Type
Technical Parameters
Film width | Max.350mm |
Bag length | 90-160 | 180-320mm |
Bag width | 50-170mm |
Product height | Max.40mm |
Rewind diameter | Max.350mm |
Packing speed | 50-250bag/min |
Voltage | 220V/380V 50HZ |
Power | 3kw |
Dimension | (L)4200×(W)1250×(H)1750mm |
Total weight | 1000Kg |
Remark | With air filling and code printer device as option |
